Description
Description
This is a high production dryer for mid to large sized shops that need outputs of 300* or 600* pcs/hr/chamber. A compact powerhouse with many advanced features such as digital temperature control, power exhaust, and air recirculation. Available in 30" (2 x 3,600w) and 54" (2 x 7,200w) belt widths.
ADVANCED
Focused Exhaust Air System evacuates fumes and moisture quicklyHEAVY DUTY
"X-Series" Conveyor Belt Tracking SystemADJUSTABLE
2" - 7" (5 - 17.7 cm) belt-to-heater height adjustmentACCURATE
Digital PID Temperature controller is accurate to +/-1°FCONSISTENT
Heavy duty DC belt speed motor with digital voltage displayINNOVATIVE
Engineered to be shorter and smaller with high heat and productionEXPANDABLE
Add 3' (.91 m) chambers and/or 18" (46 cm) / 36" (91 cm) belt extensions- Heater Warranty - 15 Year
- Defect Warranty - 3 Year
- Cure Times - 300+ Shirts Per Hour
Belt Speed - 0-16 FPM (0-4.9 MPM) - Internal Parts Material - Aluminum Coated Steel
- Insulation Type - Double Wall Air Cooled
- Exhaust (Free Air) - 320 CFM
- Overall Length - 87" (221 cm)
- Overall Width - 49" (124 cm)
- Overall Height - 53" (135 cm)
- Belt Width - 30" (76 cm)
- Chamber Length - 36" (91 cm)
- Chamber Infeed Width - 34.5" (88 cm)
- Chamber Infeed Height - 2" - 7" (5 - 17.7 cm)
- Heater Size - 2@12" x 24" (30 x 61 cm)
- Heat Range - 0 - 1000f (0 - 538c) @240v
-
Shipping Weight - 550 lbs (249.5kg)Shipping Dimensions - 54" x 50" x 60" (137 x 127 x 152 cm)
POWER OPTIONS
240V / 32A / 1 Ph. / 3 wire 50/60HZ
240V / 19A / 3 Ph. / 4 wire 50/60HZ
400V / 12A / 3 Ph. / 5 wire 50/60HZ
All amps shown are FLA (Full Load Amps), not recommended line size! This dryer must be hard wired to the power terminal provided. A licensed electrician must be consulted and should refer to articles, 210.20(a), 215.3 and 310 of the NEC code.
Available Product Options (call for configuration pricing)
- Heating chambers @ 36 in. (91 cm) long
- Belt extensions, front or rear @ 18 in. (46 cm) long
- Control box on left side (right side standard)
- Exhaust hood for extra fume extraction
- Hat support rail
- Locking casters for mobility
- Reversing belt/HD Drive
- Additional heater clearance
